主要功能和特點：

Main Structure Features:

全鋼板焊接分體式機身，由底座、立柱、橫梁三大件通過4根拉緊螺栓預緊成一體，橫梁與滑塊之間采用導柱導套方式過渡連接

Detachable steel welded frame with high rigidity, welded crown,column and bed are pretightened with tie rod bolt, transition connected by adopting guide pillar and bush between crown and slider

主傳動係統采用多連杆（八杆）傳動機構，滑塊運行中具有較高的空程速度和低而平穩的工作行程速度，滑塊行程大，承載能力強

Main drive system adopts multi-link (eight-links) drive mechanism, have high traveling speed of idle stroke and low and stable speed of working stroke, with large slider stroke and strong carrying capacity

四角八麵超長導軌導向，保證運行精度

Eeight-face rectangle guide of slide ensures running accuracy

幹式氣動分體懸掛式離合器、製動器，結合、製動力矩大，壽命長、低噪音、維修方便

Part revolusion pneumatic friction clutch and brake , with large braking torque, long service life, low noise and convenient for maintenance

液壓過載保護裝置，過載自動緊急停車 ，保護壓力機及模具的安全

Hydraulic overload protection device and overload automatic emergency stop, protect press and mold safety

稀油自動潤滑係統，具有油路報警功能

Automatic oil lubricating system, functioning of oil circuit alarm

PLC電氣集中控製，具有急停、寸動、單次、連續操作規範；帶觸摸屏顯示調整功能

PLC electrical centralized control, functioning of emergency stop,fine adjustment, single and continuous operational action; with functioning of touchscreen display and adjustment

裝模高度電動調節，數字及觸摸屏顯示

Electrical adjustment of die set height with digital and touchscreen display

可根據需要選配噸位儀、上模夾緊器 、減震墊、氣墊（可增加氣墊行程可調及閉鎖功能）等裝置。

Optional:tonnage,die holding device ,buffer and air cushion (air cushion stroke adjustable and closing function can be added)

特別適用於汽車覆蓋件的成形拉深工藝

Especially suit to forming and drawing process of automobiles panel
